| core: | |
|---|---|
| Connector Type: | |
| Quantity: | |
RW-TB-16SC
RAIWAV
RAIWAV-TB-16SC
Description
Foclink FTTH fiber optic distribution is designed to connect feeder/distribution cable to subscriber's drop cable using PLC splitter in FTTx networks. It has 16 input ports and16 output ports on the bottom and it is easy to install on the wall or pole. The rear tray is for splicing a fiber of feeder cable with PLC splitter and the front tray is for connecting subscriber's drop cable through adaptor plate on the tray.
Technical Character:
Made of cold-rolling steel, static spreading-plastic, color and lustre is uniform, elegant appearance, easy for operation.
The box has a pothook, which is convenient to install and dismantle.
The box is of unique structure, reasonable layout, and has adequate room for operation.
Adjustable clamp seal ring and reinforce configuration, which could adjust different sizes of cables flexibly to make sure the cables are tightly.
The indoor type is of excellent seal performance, which could prevent water from entering effectively.
Features：
Application
Specifications:
Environment temperature: -25℃ ~+40℃
Insulation resistance: >2*104MΩ
Humidity:≤85%(at 30℃)
Voltage Strength: 15KDC/1min, no arc-over or breakdown
Air Pressure:70kPa - 106kPa
Description
Foclink FTTH fiber optic distribution is designed to connect feeder/distribution cable to subscriber's drop cable using PLC splitter in FTTx networks. It has 16 input ports and16 output ports on the bottom and it is easy to install on the wall or pole. The rear tray is for splicing a fiber of feeder cable with PLC splitter and the front tray is for connecting subscriber's drop cable through adaptor plate on the tray.
Technical Character:
Made of cold-rolling steel, static spreading-plastic, color and lustre is uniform, elegant appearance, easy for operation.
The box has a pothook, which is convenient to install and dismantle.
The box is of unique structure, reasonable layout, and has adequate room for operation.
Adjustable clamp seal ring and reinforce configuration, which could adjust different sizes of cables flexibly to make sure the cables are tightly.
The indoor type is of excellent seal performance, which could prevent water from entering effectively.
Features：
Application
Specifications:
Environment temperature: -25℃ ~+40℃
Insulation resistance: >2*104MΩ
Humidity:≤85%(at 30℃)
Voltage Strength: 15KDC/1min, no arc-over or breakdown
Air Pressure:70kPa - 106kPa
